PCB Assembly for Medical, Industrial, IoT and Consumer Electronics
The same assembly line serves very different markets. Here is what changes when the board goes into a medical device, a factory, an IoT sensor or a consumer product.
An SMT line does not care whether the board is going into an infusion pump or a smart plug. The requirements around it do. Here is how priorities shift across four common markets, and what to put in your specification for each.
Medical devices: reliability and documentation
Diagnostic instruments, patient monitors and therapy devices are judged on one thing above all: they must work every time. That shows up as:
- Workmanship class. Many medical products are built to IPC-A-610 Class 3, the strictest level. Lower-risk devices may be Class 2.
- Clean, controlled assembly. A cleanroom environment and strict ESD control protect sensitive analog front-ends and low-signal circuits.
- Design choices that help reliability. Good grounding and separation of noisy and sensitive circuits, conservative component derating, and avoiding parts near end of life.
- Traceability and documentation. Every board traceable to component lots and test results; process changes controlled and documented.
- Testing. Functional testing of every unit, often with calibration.
Industrial automation: robustness and long life
PLCs, drives, sensors, HMIs and controllers live in factories with dust, heat, electrical noise and vibration, and they stay in service for a decade or more.
- Mixed technology. Terminal blocks, relays and power parts are usually through-hole.
- Protection. Conformal coating for dusty or humid plants.
- Long-term component availability. Choose parts with long lifecycles and approve alternates.
- Support over the product's life. Repairs, re-builds and small top-up batches years after launch.
IoT and wireless devices: small, low-power, RF-sensitive
Smart meters, trackers, telematics units, sensors and wireless modules pack a lot into a small board.
- Fine-pitch placement. Small passives, QFNs and modules need accurate placement and good paste control.
- RF performance. Antenna keep-out areas, shielding cans, impedance-controlled traces and consistent soldering of RF parts. Small variations between boards can change radio performance.
- Low power. Leakage from flux residue or contamination can drain batteries, so cleanliness matters.
- Testing. Programming and radio testing of every unit, not just a sample.
Consumer electronics: cost, speed and volume
Consumer products are built in volume and live on short development cycles and tight margins.
- Design for cost. Fewer layers, standard parts, single-sided placement where possible.
- Fast ramp-up. Quick prototyping, fast DFM feedback and a smooth move to volume.
- High yield. Automated inspection keeps scrap down at scale.
- Cosmetics. Visible parts, displays and enclosures matter to the buyer.
Class 1 or Class 2 workmanship is typical.
Comparison
Medical | Industrial | IoT / wireless | Consumer | |
|---|---|---|---|---|
Typical IPC class | 2–3 | 2 | 2 | 1–2 |
Top priority | Reliability, traceability | Robustness, long life | Size, RF, power | Cost, speed |
Coating | Sometimes | Often | Sometimes | Rarely |
Testing | Every unit, calibration | Every unit | Every unit incl. radio | Every unit, fast |
Volumes | Low–medium | Low–medium | Medium–high | High |
One partner, many markets
Polyfit's EMS division builds for medical devices, industrial automation, consumer electronics, telecom, energy systems and defence electronics, as well as automotive and EV customers. Assembly happens in a Class 10K (ISO 7) cleanroom to IPC-A-610, with SPI, AOI, functional testing and conformal coating. Tell us about your application.
